Ample Chip offers professional SMT and PCBA services with fast turnaround. We provide high-speed SMT assembly, component sourcing, and support small to large batch production. Get your PCBA ready in as fast as 24 hours.
| Project | Processing capacity | Process details | Graphic and textual explanations |
|---|---|---|---|
| Number of layers | Floors 1 to 20 | The number of layers refers to the number of electrical layers (copper-clad layers) in a PCB. | At present, there are only 1 to 20 layers of perforated plates |
| Laminated structure | 4 floors,6 floors,8 floors,10 floors | Check the lamination structure | The multi-layer board supports impedance design and the impedance board is not charged separately |
| Plate type | FR4 (Grade A) | Single-sided, double-sided, four-layer, six-layer, eight-layer to twenty-layer boards. The sheet materials include Grade A sheet materials such as "Taiwan Nanya", "Jiantao KB", "Shengyi", and "hongruxing" | |
| High-frequency board | Currently, it is produced as "double-sided high-frequency board (10Z copper thick)": ceramic material and Teflon (PTFE) sheet material | ||
| Aluminum substrate | It is currently fabricated as a "single-sided aluminum substrate". | ||
| Copper substrate | Currently, we are manufacturing "single-sided thermoelectric separation copper substrates" (with the length and width of the boss ≥1mm). | ||
| The entire system process | Maximum size | 400x500mm | The working board size is 400x500mm. Generally, the PCB design size of customers is allowed to be within 380x380mm |
| Minimum size | 5x5mm | Small-sized plates are recommended to be pieced together for processing. | |
| Plate thickness range | 0.4~2.0 mm | Current production FR4 board thickness: 0.4/0.6/0.8/1.0/1.2/1.6/2.0 mm | |
| The outer layer is copper thick. | Finished copper thickness :10Z,20Z | Take the four-layer board as an example | |
| The inner layer is thick with copper | Finished copper thickness :0.50Z,10Z,20Z | ||
| Circuit production | Graphic electroplating (traditional tin plating cathode process) | The disastrous negative film process has emerged again, using this process as a quality disaster. | |
| Solder mask type | Photosensitive ink green,Purple,red,yellow,blue,white,black | Photosensitive ink is the most widely used type nowadays, while thermosetting oil is generally applied to low-grade single-sided cardboard | |
| Surface coating | Leaded tin spraying, lead-free tin spraying, gold plating | All FR4 sheet materials can be produced by these three processes. Aluminum substrates are only used for tin spraying, and copper substrates are only used for OSP |
| Project | Economic type | Standard type |
|---|---|---|
| Welding surface | Single-sided soldering (surface mount + through-hole) | Single/double-sided soldering (surface mount + through-hole) |
| Number of layers | 2.4, 6th floor | Unlimited |
| Plate thickness range | 0.8mm - 1.6mm | Unlimited |
| Size | 10 * 10mm-470 * 500mm | 70 * 70mm-460 * 500 |
| Quantity | Sample (≤30(50) large pieces) | Minimum application: 2 pieces, no upper limit |
| Pad spray coating | There are restrictions. | Unlimited |
| PCB color | There are restrictions. | Unlimited |
| PCB shipping method | Single board, stamp hole assembly | Single board, stamp hole panel, V-cut panel |
| Craft Side | No need | Must |
| Mark point | No need | Need |
| SPI tin nurturing test | No. | risk |
| AOI | Mixed inspection | Individual detection |
| Minimum package | 0402 | 0201 |
| Minimum package | 0402 | 0201 |
| Minimum NIC pin spacing | The 0.4 mm | The 0.35 mm |
| BGA ball diameter pitch | The 0.5 mm | The 0.5 mm |
| Reflow soldering temperature | 255+/-5 degrees (not adjustable) | 240+/-5 degrees |
One of the key advantages of working with Ample-Chip is their comprehensive product range. They offer a wide variety of chips and related components from major manufacturers, ensuring that customers can find the products they need in one place. This eliminates the need to work with multiple suppliers and simplifies the procurement process.
Ample-Chip's long-standing relationships with major manufacturers enable them to offer competitive pricing to their customers. By leveraging their purchasing power and knowledge of the market, they can provide cost-effective solutions that meet the needs of their customers.
Ample-Chip has an established logistics network that allows them to provide fast and reliable delivery to customers worldwide. They work closely with trusted carriers to ensure that products are delivered on time and in the right condition.
Customer service is a top priority at Ample-Chip. Their experienced and knowledgeable staff are dedicated to providing personalized support to each customer, from technical assistance to logistical support. They are committed to ensuring that customers receive the highest level of service and support throughout the procurement process.
Ample-Chip is committed to ensuring the quality of their products. They work closely with their suppliers to ensure that all products meet or exceed industry standards, and conduct rigorous quality control testing on all products before they are shipped to customers. This ensures that customers receive products that are reliable and meet their specifications.
Ample-Chip is committed to providing innovative solutions to help customers manage their inventory more efficiently. They offer services such as excess inventory management, chip substitutions, and free component sourcing to help customers reduce costs and optimize their inventory.
