NX7002BKMBYL

Manufacturer Part NX7002BKMBYL
Manufacturer Rochester Electronics
Description NX7002B - 60V, N-CHANNEL TRENCH
Category Discrete Semiconductor
RoHS Lead free / RoHS Compliant
Warranty 365 days
Datasheet NX7002BKMBYL PDF
Product Attributes
Type Description
Series:TrenchMOS™
Package:Bulk
Part Status:Active
FET Type:N-Channel
Technology:MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):60 V
Current - Continuous Drain (Id) @ 25°C:350mA (Ta)
Drive Voltage (Max Rds On, Min Rds On):5V, 10V
Rds On (Max) @ Id, Vgs:2.8Ohm @ 200mA, 10V
Vgs(th) (Max) @ Id:2.1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:1 nC @ 10 V
Vgs (Max):±20V
Input Capacitance (Ciss) (Max) @ Vds:23.6 pF @ 10 V
FET Feature:-
Power Dissipation (Max):350mW (Ta), 3.1W (Tc)
Operating Temperature:-55°C ~ 150°C (TJ)
Mounting Type:Surface Mount
Supplier Device Package:DFN1006B-3
Package / Case:3-XFDFN
More Information
NX7002BKMBYL
NX7002BKMBYL
Rochester Electronics NX7002BKMBYL is available at Ample-Chip.com. We only sale New&Original Part and offer 1 year warranty time. If you would like to know more about the products or apply more better price, please send a quote to us or contact us by email.
Documents
Datasheet
NX7002BKMBYL PDF
